In most areas, burying the pipes 8 to 12 inches below the surface is adequate. This measurement is from the top of the pipe to the surface of the soil, which means your trenches must be slightly deeper to accommodate the pipes.

How deep should I trench for sprinklers?

Dig for Your Sprinkler System The trenches will be relatively shallow, usually 6 to 12 inches deep, depending on your area’s freeze cycles and frost severity. The trench must also be deep enough to allow the sprinklers to retract underground to prevent breakage from lawn machines.

How deep should you dig when adding sprinklers to your house?

Dig trenches following the string. Mark the sprinkler locations with flags or the stakes. Typical trench depths range from 6 to 12 inches. To run pipe under existing walkways you can “drill” using water pressure.

Should sprinkler heads be flush with the ground?

Sprinkler heads sit just below or flush with the ground, so a sturdy trowel is typically suitable for digging up the head. … Then dig a hole about 6 inches deep and a foot in diameter around the broken sprinkler head, taking care not to puncture the water line with your trowel.

How do I stop my sprinkler lines from digging?

  1. Look at the design map given to you by your installation company. …
  2. Locate where a line should be at the edge of the map that crosses the area where you will be working. …
  3. Mark the area with a flag.
  4. Dig down in the area marked, using a hand trowel.

What is the minimum distance between sprinkler heads?

Current fire safety codes require sprinkler heads always to be a minimum of 6 feet apart from one another to avoid cold soldering.

How high should lawn sprinklers be?

The correct height for a sprinkler head is to have the top of sprinkler head just above the soil surface. No more than a quarter of an inch above the ground level. This lowers the tripping hazard, and a lawn mower can go past it without causing any damage.

How do I dig my lawn for sprinklers?

Slide the shovel tip under the grass roots and lift up the grass. Place the grass on garbage bags on one side of the trench. Dig out the loose soil underneath and place it on garbage bags on the opposite side of the trench. Continue this process to dig all irrigation lines.

How is sprinkler height measured?

The size of a sprinkler is determined by the height of the stem – the part that pops up. The part that stays in the ground is called a canister and should NOT be measured to determine size. Do NOT measure the entire sprinkler, either, meaning the canister and the pop-up.

What size are sprinkler lines?

When you install a sprinkler system, you might use PVC or polyethylene piping to deliver water to the sprinkler heads. If you use PVC, the typical diameter of the pipes is between 1/2 inch and 2 inches. The right size pipe depends on the overall capacity of your system.

Article first time published on

How high should sprinkler heads be before sod?

The sprinkler heads should extend about 5/8-inch above the ground before sod is laid and should be level with the sod root base afterward.

How do I find buried sprinkler lines?

You can tell (roughly) where the pipes will be for that zone by finding the shortest path from the valve box that connects all the sprinklers in a zone. As long as you dig carefully, you shouldn’t have too much trouble. The pipes are usually pretty tough and are usually buried about a foot or so under the ground.

How many sprinklers can I put on one zone?

At different pressures, the sprinkler head and nozzle will consume different amounts of water. For example, at 35 pounds per square inch (PSI) the 5000 Series Rotor using the 3.0 nozzle will use 3.11 gallons per minute (GPM). If your home’s water capacity was 10 GPM, you could place 3 heads per zone.

Can you plant over a sprinkler line?

In general, a sprinkler system line that is in the top 12″ of soil won’t be bothered by tree roots. (Deeper lines can be compromised by tree roots.) If the trees you are growing tend to develop surface roots rather than a deep root system, the surface roots can cause problems with the lines.

What is the best tool for digging a trench?

  • Corona SS General Purpose Trench Shovel. If you’re digging a drainage trench or laying a water pipe by hand, a trenching shovel is a must-have tool. …
  • Tabor Tools Pick Mattock. …
  • True Temper Drain Spade. …
  • Ames Saw-Tooth Border Edger. …
  • True Temper Bow Rake.

How much should I pay for trenching?

Digging a trench amounts to an average of $8 per linear foot, including equipment and labor. Doing it yourself eliminates labor and puts the price at an average of $2.25 per linear foot. *Labor rate includes support materials and cleanup. Most trenches are 24 inches deep and 8 inches wide.

Can you trench with a chainsaw?

Yes! Chainsaws are great for digging trenches but there are some downsides so make sure you weigh all of your options before deciding what method will work best for this project.

What is the maximum height of sprinkler head?

The maximum ceiling height shall be 40 ft. The minimum operating pressure shall be either 30 psi or 60 psi based upon the applicable storage and ceiling height for the installation as follows: 30 psi for storage heights up to 25 ft.

How do I choose a pop up sprinkler?

When selecting popups, consider the height of the lawn, make sure you select a sprinkler that is able to project over grass at its tallest. The output of a Popup Sprinkler is totally dependent on the nozzle that is fitted.

Can sprinkler heads be too close together?

Minimum and maximum distances between the most common sprinkler heads—and from heads to walls—receive careful attention in NFPA 13. … Placing sprinklers too close to walls, to each other, or to obstacles can make a fire much more likely to spread.

How far can a sidewall sprinkler spray?

Distance from Sidewall Sprinkler to Side of Obstruction (A)Maximum Allowable Distance of Deflector Above Bottom of Obstruction (B) [in. (mm)]5 ft 6 in. (1.7 m) to less than 6 ft (1.8 m)3 (75)6 ft (1.8 m) to less than 6 ft 6 in. (2.0 m)4 (100)6 ft 6 in. (2.0 m) to less than 7 ft (2.1 m)6 (150)

What is the maximum allowable distance between two sprinklers?

1 of NFPA 13, which states that the distance from the sprinkler to the wall can be no more than one-half the allowable distance between sprinklers. The max distance between standard spray sprinklers in light hazard settings is 15 ft. (4.6 m) (with exceptions for light-hazard, combustible concealed spaces).

How far does a pop-up sprinkler spray?

For these reasons, they are the most commonly used kind of sprinkler head. The elevation of common pop-up devices ranges from 2 to 20 inches. Each body and nozzle is typically designed to deliver water anywhere from 3 to 15 feet.

How do you backfill a sprinkler trench?

  1. Backfill trenches 1/2 full. Do NOT install sprinklers yet.
  2. Flush entire system for 5 minutes with all valves open.
  3. Cap all sprinkler risers leaving only one open and flush for 2 minutes. …
  4. Finish backfilling trenches, don’t backfill around the risers.

How do I dig a trench in my lawn?

Take your trenching shovel and remove the soil, and place the removed soil into plastic bins all along your trench. This makes replacing the soil far easier and prevents your yard from being turned into a big mess. Once the trench has been dug, you can lay down whatever you dug the trench for.

Should I use 13mm or 19mm poly pipe?

Poly pipes or irrigation pipe is made of black polyethylene. … As a general rule, 13mm pipe can be used for drippers, but 19mm will feed more emitters. Sprayers need 19mm pipe, and pop-ups usually require 19mm or 25mm depending on water pressure.

Which pipe is best for sprinkler system?

Polyethylene is the best bet for special situations in areas where sprinkler and irrigation systems require flexibility. Both types of pipe are durable and can withstand many elements in the environments where they excel.

What is class 200 PVC pipe used for?

PVC Class 200, 160 and 125 pressure pipe are used in rural water systems, agricultural and turf irrigation and as sewer force mains.

How deep do you bury a sprinkler head?

The depth should be around 6-8 inches to give you some room to work. Carefully lift the grass around the sprinkler head and flip it upside down on the lawn. With a small trowel, remove the dirt from around the sprinkler head taking care not to hit the sprinkler line.

Do I need to rototill before laying sod?

While rototilling before laying sod gives the roots loose soil to grow into, as well as working the old sod and weeds into soil rather than digging them out by hand, other soil preparation methods also work well in helping sod to take properly.

Should I put topsoil down before sod?

Adding topsoil is not essential for sod but it will provide some benefits. … If you cannot have the topsoil mixed into the existing soil, then do not apply it! A thin layer of topsoil prevents grass plants from rooting deeply.
