In the ConfigurationManager, right-click Design Table and select Edit Table or Edit Table in New Window. … Edit the table as needed. … Click outside of the table to close it. … If you receive a confirmation message that the design table generated new configurations, click OK.

How do I edit a general table in Solidworks?

  1. Double-click the design table in the drawing. The model opens in its own window, and the design table opens for editing.
  2. Modify the table as needed. When you are done, click outside of the table to close it.
  3. Return to the drawing window, and click Rebuild to see the updated table.

How do I open a design table in Solidworks?

Select design table settings when you insert a design table. To open this PropertyManager: In a part or assembly document, click Design Table (Tools toolbar) or Insert > Tables > Design Table.

How do I edit a table template in Solidworks?

TableFile Name ExtensionTitle Block Table.sldtbt

How do I add a part to a table in Solidworks?

  1. In a drawing of the part or assembly, select a drawing view.
  2. Click Insert > Tables > Design Table. The design table appears, and you can drag it into place on the sheet.

How do you create a custom table in Solidworks?

  1. Open a model that contains the characteristics needed for the template: Components. …
  2. Insert a table. In the table PropertyManager, specify one of the standard templates shipped with the SOLIDWORKS software; for example: …
  3. Edit the table as described below, then save the table as a template.

How do I edit the bottom table in SolidWorks?

  1. In the ConfigurationManager, right-click Design Table and select Edit Table or Edit Table in New Window. …
  2. Edit the table as needed. …
  3. Click outside of the table to close it.

How do I add a column to a design table in SOLIDWORKS?

To add rows and columns to the design table: In the Add Rows and Columns dialog box, select the configurations and parameters you want to add from the Configurations and Parameters boxes. To select multiple features, hold down Ctrl as you select.

What is design table solidworks?

A design table allows you to build multiple configurations of parts or assemblies by specifying parameters in an embedded Microsoft Excel worksheet. The design table is saved in the model document and is not linked to the original Excel file.

How do you add dimensions to a design table in SOLIDWORKS?

To do this, start by going to the configuration tab, right click on design table, and click edit design table. Click on the cell to the right of the last dimension. Go to the part tree, click on the sketch and then click on the dimension that needs to be added to the design table.

Article first time published on

How do you delete a design table in SOLIDWORKS?

  1. Right-click Design Table in the ConfigurationManager and select Delete.
  2. Click Yes to confirm the deletion. The design table is deleted, but the configurations are not.

How do you add a design table?

  1. In a part or assembly document, click Design Table (Tools toolbar) or Insert > Tables > Design Table.
  2. In the PropertyManager, under Source, select Auto-create.
  3. Set the Edit Control settings and Options, as desired.
  4. Click .

How do I create a design table in SOLIDWORKS assembly?

You can select design table settings when you insert a design table. The Dimensions dialog box appears after you select the Auto-create option in the Design Table PropertyManager and click OK. The SOLIDWORKS software asks you which dimensions you want to add to the design table.

How do I make a design table?

  1. Select Create > Table Design.
  2. In the new table, for the first field, enter a field name and a data type.
  3. To set the primary key for the table, select the Field Name cell for the appropriate field and then select Primary Key. …
  4. Select File > Save, and name the table.

How do you edit text in Solidworks?

  1. In an open sketch, right-click the text (the pointer changes to when it is over the sketch text) and select Properties.
  2. Edit the text and its properties in the Sketch Text PropertyManager as necessary.

How do you edit text in title block in Solidworks?

  1. Do one of the following: …
  2. Drag a corner to resize the rectangle laid over the title block area. …
  3. Select notes in the title block. …
  4. Click arrows or. …
  5. To aid users, type informational text for each selected note in the Tooltip field.
  6. Click .
  7. Save the drawing as a template.

How do I add a sheet in SolidWorks?

To add a sheet: Click Insert > Sheet. You can also right-click any sheet tab or any sheet icon in the FeatureManager design tree, and select Add Sheet.

How do I change the default sheet format in SolidWorks?

  1. Click Options. or Tools > Options.
  2. Select Default Templates.
  3. Click the appropriate browse button (Parts, Assemblies, or Drawings).
  4. In the New SolidWorks Document dialog box, select the template you prepared and click OK.
  5. Select: Always use these default document templates. …
  6. Click OK.

How do you update a BOM table in Solidworks?

  1. In the View section of the Bill of Materials tab, expand BOM , and select a named BOM. …
  2. Click Refresh ( or ).
  3. In the Update Source Version dialog box, expand the File Version list and select the version to use. …
  4. Click OK.

How do I change the part number in Solidworks?

  1. Under Part Numbers, select the part number saved settings.
  2. Click Edit.
  3. In the Part Number dialog box, change Part number, Description, or both.
  4. Click OK.

How do I add a feature to a design table in Solidworks?

Right-click an item and select Configure dimension, Configure feature, or Configure component. Then select Auto-create in the Design Table PropertyManager when you create the design table. Search ‘Manually Add Parameters in a Design Table’ in the SOLIDWORKS Knowledge Base.

How do I change the configuration in Solidworks?

  1. In the ConfigurationManager , right-click the configuration name, and click Properties.
  2. Specify options in the PropertyManager. Click Custom Properties to add or modify custom properties for the configuration.

What program do you need to create a design table?

Design Tables are Excel spreadsheets which are embedded in a SOLIDWORKS part or assembly. The layout of a Design Table is very similar to that of a Configuration Publisher, in that features and components can be suppressed, dimensions changed and Configuration Specific Properties set.

Where is Configuration Manager in Solidworks?

Click the ConfigurationManager tab at the top of the Manager Pane.

How do I use Excel in Solidworks?

  1. In a part or assembly document, click Design Table (Tools toolbar) or Insert > Tables > Design Table.
  2. In the PropertyManager, under Source, select From file, then click Browse to locate the Excel file.
  3. Optional: Select Link to file, which links the table to the model.

How do I change the color of a table in Solidworks?

Click Edit Appearance (Standard toolbar) or Edit > Appearance > Appearance. In the PropertyManager, under Color: Click a color in the palette. Select RGB.

How do I create a design table in Solidworks 2020?

  1. In a drawing of the part or assembly, select a drawing view.
  2. Click Insert > Tables > Design Table. The design table appears, and you can drag it into place on the sheet.
