Duct board consists of compressed fiberglass backed with a foil vapor barrier. The insulating qualities of compressed fiberglass reduces the temperature loss from air moving through the plenum and stops condensation from forming on the exterior surface of the duct plenum.

Can you use duct board as a plenum?

The plenum is usually made from sheet metal and is connected to the supply outlet of an HVAC system. … The difference between the listings is that tapes that meet both listings (UL 181A-P/B-FX) can be used on rigid fiberglass duct board, flexible air duct and sheet metal.

What is the purpose of a plenum?

Plenum boxes are usually situated on either side of the fan or heat exchanger and have the important function of bringing in, distributing, and removing air. They are the air’s first stop after being heated or cooled and its last stop before going back into your AC, heat pump, or furnace.

What is the difference between a plenum and a duct?

A plenum is an air distribution box designed for forced-air systems on residential homes and commercial businesses. It is part of the ductwork, but far different than an air duct as these important boxes handle air as it enters the ducts and helps to recirculate it within a system.

What does duct board mean?

Duct board is a semi-rigid fiberglass insulation material often used for residential or light commercial heating and cooling applications in lieu of metal duct.

Why do we use plenum in HVAC?

Plenum boxes are used to distribute heated or cooled air throughout your home’s interior. After producing heated or cooled air, the HVAC system must move that air through the ductwork. Plenum boxes take in this air so that it can be pumped into the ductwork and, therefore, distributed throughout your home’s interior.

How long does duct board last?

Ductwork has a maximum lifespan of 20-25 years. By 15 years, however, it begins to deteriorate, significantly reducing your HVAC system’s efficiency, so replacement is the prudent option.”

How do you remove mold from plenum?

Use an EPA registered disinfectant labeled for HVAC use to clean non-porous surfaces (Ductwork, coils, plenums, pans, etc) of mold, mildew, and other dirt. BIOSPRAY-TOWER ready-to-use disinfectant and mold cleaner will kill and remove mold, mildew, and odor-causing bacteria.

What is stack duct?

Used between wall studs for venting, heating & air conditioning supply & return duct.

Do I need plenum cable in my house?

If there is no sheet metal duct; just the open ceiling or wall space, then you are required by law to use Plenum Rated cable. … The lack of wall or ceiling return air grates is usually a sure sign that you require Plenum Rated Cable.

Article first time published on

What is an open plenum?

A plenum space is a part of a building that can facilitate air circulation for heating and air conditioning systems, by providing pathways for either heated/conditioned or return airflows, usually at greater than atmospheric pressure.

What is the R value of duct board?

The 1-inch fibrous glass duct board has an R-value at 75°F of 4.3 h•ft2•°F/Btu. The 1½-inch board has an R-value of 6.5.

Are fiberglass ducts safe?

Fiberglass. … When ducts are damaged or deteriorating, they can introduced particles of fiberglass into the air you breath. According to the American Lung Association– Inhaling fiberglass can reduce lung function and cause skin eye and throat irritation, in humans and animals.

Can you use duct board on a furnace?

Standard uncoated fibrous glass duct board may be used after the first four feet of coated duct. For a horizontal supply system with a horizontal return, again, standard uncoated fibrous glass duct board may be used in the return adjacent to the furnace fan, as shown in Figure 4.

Can I use foam board for ductwork?

Rigid foam board ducts can be installed during new home construction or a remodeling project. You can build ducts from rigid foam board to serve as the distribution system to circulate heated or cooled air in your house.

Where is the supply plenum?

A supply plenum is an enclosed compartment that’s located just after your heat exchanger if you follow the flow of air through your furnace (see below). When your air handler blows air over your system’s heat exchanger, that warm air is directed into the supply plenum.

Can duct board be cleaned?

Although fiber board and duct board products are designed to withstand cleaning, only an experienced duct cleaner should be trusted. They are made of fiberglass and small particles become airborne during the cleaning process. … Sanitizer can be used to inhibit or kill microbial growth which is common on insulated ducts.

What is the average cost to replace ductwork?

The average cost to replace ductwork is $1,400 to $5,600, depending on the home’s size. Air duct replacement costs $25 to $55 per linear foot or $270 to $500 per duct for a crawl space, attic, or basement. New ductwork installation costs $2,400 to $6,600 for a house without HVAC ducts.

Is duct board fire resistant?

Owens Corning QuietR™ Duct Board is a rigid, resin bonded fibrous glass board with a tough, damage-resistant, flame retardant, reinforced aluminum foil (FRK) facing.

How does plenum ventilation work?

Supply plenum supply ventilation air to the occupied space, whilst return air is generally extracted through ductwork. … Conversely, in return plenum the air is generally ducted to the space, whilst the return air is extracted through the plenum.

What is a plenum slab?

An underfloor plenum is the open space between a structural concrete slab and the underside of a raised access floor system. Commonly used as the service plenum for distributing power, voice, and data cabling, in UFAD systems supply air is also delivered through this space.

What is the duct?

Ducts are conduits or passages used in heating, ventilation, and air conditioning (HVAC) to deliver and remove air. The needed airflows include, for example, supply air, return air, and exhaust air. Ducts commonly also deliver ventilation air as part of the supply air.

What are standard duct sizes?

Rectangular HVAC Duct Sizing Rectangular or square ducting comes in standard sizes ranging from 3 inches by 7 inches to 35 inches by 40 inches. Sizing is based on airflow needs per cubic foot per minute, as well as velocity.

What is Wall duct?

Wall duct is a UL Listed, metal raceway used to enclose the wiring to diagnostic-imaging machines. Wall duct is used in combination with trench duct to provide a complete raceway system from the power and control consoles to the patient table. The raceway system enables a complete lay-in system.

How can you tell if you have mold in your air ducts?

  1. Strong musty odors.
  2. Black spots around vents, ducts, or drip pans.
  3. Allergy symptoms.
  4. Difficulty breathing.
  5. Persistent headaches.
  6. Nausea or dizziness.
  7. Fatigue.

What causes mold in plenum?

For example, the plenum, or air box on the supply side, can sometime leak, leading to mold inside. In some cases, this can be cleaned, but other times it is better to replace it. Likewise, flexible ducting is not easily cleaned and if mold-ridden, should be replaced with new duct work material.

Can mold grow in HVAC ducts?

Mold grows in ductwork when two things are present: moisture and warm temperatures. A warm, humid environment has the ideal conditions for mold to form. A humid climate along with poor ventilation, or anything that traps moisture in your walls and causes condensation, can lead to mold in air ducts.

Why would you use plenum cable?

Plenum spaces allow fire and smoke to travel quickly. By using plenum-rated cable, the levels of toxicity in the smoke would be lower since plenum cable is coated with a jacket that is typically made of flame-resistant material such as Teflon.

What is considered a plenum?

In building construction Plenum is a separate space provided for air circulation for heating, ventilation, and air-conditioning. It is commonly found in the space between the structural ceiling and a drop-down ceiling or under a raised floor.

What is the purpose of plenum cable?

Plenum rated cable has a special insulation that has low smoke and low flame characteristics. Plenum cable is mandated to be installed in any “air handling” space. For example, most large office buildings use the ceiling to return air to the AC unit.

How do you identify a plenum ceiling?

A plenum ceiling is one that uses the space between the top of the suspended ceiling and the bottom of the floor above to handle air for ventilation. All suspended ceilings are not plenums; some may use HVAC ductwork to move air to returns and diffusers located in the ceiling tiles (a ‘dead’ ceiling).
