shotcrete, also called (trademark) Gunite, concrete applied by spraying. Shotcrete is a mixture of aggregate and portland cement, conveyed by compressed air to the nozzle of a spray gun, where water is added. The wet mixture is then sprayed in place and may be carved or troweled almost immediately.

What is the purpose of shotcrete?

The use of shotcrete-sprayed concrete in construction activities makes the structure less porous which increases the bond strength and also helps in lowering the construction time and reduces costs as well.

What is the composition of shotcrete?

Shotcrete typically consists of one part cement and four parts sand by weight with approximately 7% water by mass of dry ingredients. It can also include coarse aggregate and admixtures. Dry mix shotcrete involves the premixing of dry ingredients with water added at the nozzle.

How is shotcrete different from concrete?

Traditionally, concrete has been poured from a ready mix truck onto a project site. It is either placed on the ground or into forms, and then vibrated to flush out air and to make sure that it is compact. … Shotcrete involves applying the concrete after it is already mixed.

Is shotcrete stronger than concrete?

The ability to build in very tight spaces and “free form” applications make it very simple to build pools of any shape. Higher compressive strengths than cast-in-place concrete. Typical compressive strengths of shotcrete are in the 6,000 to 7,500 psi range. Lower construction costs.

How thick can shotcrete be applied?

There is no stated maximum thickness for shotcrete used in shear walls or any other type of wall. Walls have been successfully placed to a thickness of 36 in. (914 mm) for some time. The two main concerns are the heat of hydration and proper encapsulation of the reinforcing steel.

Can cement be sprayed?

There are many applications and uses for sprayed concrete. … Dry process sprayed concrete: a predetermined dry mix of cement and aggregate is propelled through a spraying nozzle, where a finely atomised spray of water is added to the stream of materials to hydrate the cement.

Is shotcrete considered cast-in-place?

Shotcrete is pneumatically applied concrete and is an alternate means and method that offers cost savings in the construction of basement foundation walls compared to cast-in-place (CIP) concrete construction.

Is shotcrete more expensive than gunite?

Gunite generally allows builders to take more time to complete the project properly, since they can stop and start as needed. Gunite tends to be less expensive than shotcrete, and it can result in fewer errors in the construction process.

How long does shotcrete take to dry?

Concrete, when applied using the shotcrete process, or cast-in-place, needs to cure for 7 days. Water is the best curing method (7 continuous days).

Article first time published on

Can you pour shotcrete in the rain?

Shotcrete needs to be protected from rain until it obtains its final set, usually 4 or 5 hours. Following final set, it should be wet cured for at least 4 days, preferably 7 days if possible. The exposure to rain would prove beneficial as the rain would assure the presence of moisture for continued curing.

How does shotcrete stick?

Fine material penetrates rock pores and cracks, providing a surface for larg- er particles to stick and build surface thickness. N o t e : A clean rock surface, allowing for a strong initial bond, is critical to stabi- lizing rock surfaces with shotcrete. 1.

What is the lifespan of shotcrete?

The durability of shotcrete is equivalent to high-quality concrete. The life span of a new construction shotcrete structure is more than 50 years. For rehabilitation projects, shotcrete can extend the life of a structure by more than 25 years.

Which is better gunite or concrete?

Unlike concrete, when building gunite pools, you can stop and start without any problems, which will help give a smoother finish. … Using gunite can be more time-consuming to apply than concrete because you need to do the mixing on-site, and there could also be hold-ups if the dry mix clogs up pipes during the process.

What are shotcrete walls?

Shotcrete is pneumatically placed concrete that is used to create vertical slabs, round columns and rounded or decorative walls. A faster process than horizontal concrete, shotcrete can reduce days on your project schedule through less forming and cleanup.

How long does it take to shotcrete a pool?

This takes up to 28 days and is achieved through soaker hoses that spray the pool walls and continuously recycle the water. Reputable high-end builders are experienced in all of these critical processes, giving you the peace of mind that your pool is built to last.

What is better gunite or shotcrete?

Durability. Gunite generally lasts longer and maintains a higher quality than shotcrete. For instance, gunite tends to dry faster than shotcrete, leading to a much smoother surface and avoiding significant cracks from shrinking. Gunite can also withstand up to 9500 psi, a much higher psi than shotcrete.

Can you shotcrete yourself?

DIY shotcrete is achievable for a hobbyist, owner/builder or a contractor. It is all about the speed of delivery you want to accomplish. … Before getting started, decide if you want to spray ready mix or site batched shotcrete.

What type of concrete is sprayed?

Shotcrete, gunite (/ˈɡʌnaɪt/), or sprayed concrete is concrete or mortar conveyed through a hose and pneumatically projected at high velocity onto a surface, as a construction technique, first used in 1907 invented by Carl Akeley. It is typically reinforced by conventional steel rods, steel mesh, or fibers.

What is the slump of shotcrete?

Slump: A 2″ to 3″ slump is typical for a shotcrete mix, compared to a 4″-5″ slump for a cast in place mix. Aggregate Size: The large aggregate size used for shotcrete is typically 1/2″ and smaller.

How much does spray concrete cost?

Spray-on coloured concrete may cost between $70 and $95 per square metre.

How thick should a concrete pool be?

To be structurally sound, a concrete pool shell should generally be 6 inches thick. Depending on the engineer and the soil condition, it may be more. (On top of that, the plaster interior finish should be at least ⅜ inch thick.)

What is the difference between Marcite and gunite?

A gunite pool’s biggest pro is having the most durable finish of any swimming pool surface. … While Marcite plaster is the least expensive of the gunite pool surfaces, it does have its disadvantages. The surface can start to show visible chipping or etching after 5 to 7 years.

What psi concrete is used for pools?

In California, building officials typically mandate 2,500 psi shotcrete for pools.

What are pools sprayed with?

Gunite and shotcrete are forms of pneumatically applied concrete, meaning they are sprayed on with a high-pressure air hose. Crews shoot the material over a reinforcing network of steel bars.

What makes a concrete pool waterproof?

In order to waterproof swimming pools, it is recommended to use epoxy-cement systems as they create a solid barrier against counter pressure as well as a resistant layer.

Do you have to keep shotcrete wet?

A: The gunite shell must be maintained moist for at least 7 days after application is completed. … You can apply a light mist of water hours after the gunite application is completed. The next days you can apply a heavy spray to moisten the gunite. You cannot apply too much water.

What happens if you dont water shotcrete?

Lack of curing and exposure to windy, hot, or dry conditions will certainly increase the potential for shrinkage and cracking of the concrete. Lack of curing will prevent the concrete from achieving its maximum potential strength.

Do you have to water shotcrete?

Shotcrete / concrete is ready for water as soon as the initial set is complete, which is about 4-6 hrs after placement. Water is applied to aid in hydration/curing, a process which decays exponentially, so watering is most critical in the first hours/days after placement.

How long after gunite Can you plaster?

Prior to plaster: 3 weeks While the gunite is curing, the beginning of many other processes will begin. During the three-to-four-week curing process, you can expect to see tile and coping take place (plus any additional stonework that may include grills, fireplaces, and firepits).

Can you pour concrete for a pool in the rain?

Because it is a chemical reaction, concrete can be formed in wet conditions and will still harden. In fact, concrete sets better if it is kept wet as long as possible. Placing concrete in rainy conditions can lead to several problems.
