The first number, when multiplied by 2, tells you how wide of a fan the tip will create when sprayed at a distance of 12 inches from the surface. The second two numbers are the orifice size of the tip, in thousandths of an inch, that determines how much fluid will leave the spray tip.
What do the numbers mean on a spray nozzle?
Most companies identify their flat-fan nozzles with a four or five digit number (Figure 2). The first numbers are the spray angle and the other numbers signify the discharge rate at rated pressure. For example, an 8005 has an 80 degree spray angle and will apply 0.5 gallons per minute (GPM) at rated pressure of 40 psi.
What is a 210 spray tip used for?
Fine finish spray tips are used for cabinetry, furniture and interior trim work (for a smooth fine finish) example Graco FF LP spray tips: 210 or 310. Low pressure tips are used primarily for spraying with pressures between 55 to 76 bar (800 to 1100 psi).
How do you know what size spray tip to use?
- The first digit is half of the fan width, the “5” in “517” equals a 10 inch spray fan width (5 x 2 = 10)
- The last two digits are the size of the tip opening in thousandths of an inch, the “17” in “517” means the tip hole size is . 017 inch.
What is a 215 spray tip used for?
The 215 SwitchTip has a 0.015 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs. Used for residential, commerical or industrial applicaitions. Best used with materials ranging from lacquers, latex paints and mastics.
What is a 413 spray tip used for?
The Reverse-A-Clean (RAC) 413 RAC IV SwitchTip is designed for narrow surfaces and thinner materials like stains and polyurethanes. The 413 SwitchTip has a 0.013 inch orifice and produces an 8 to 10 inch fan. Reverse the SwitchTip to easily clear clogs.
What is a 311 spray tip used for?
The reversible RAC IV SwitchTips are the most widely used tip for spraying a variety of coatings from lacquers to exterior paints. Use the Reverse-A-Clean (RAC®) feature to quickly clear tip clogs by simply twisting the tip and spraying in the reverse position.
What is a 519 spray tip used for?
Achieve greater control and less overspray on different surfaces with a wide range of coatings, from stains to exterior paints. 10 inch spray pattern ideal for larger surfaces such as houses/buildings, walls and ceilings.What is a 217 spray tip used for?
The 217 SwitchTip has a 0.017 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs. Used for residential, commerical or industrial applicaitions. Best used with materials ranging from lacquers, latex paints and mastics.
What is a 315 spray tip used for?The 315 tip is ideal for fence picket priming and painting. The 6” fan pattern minimizes overspray when spraying pickets.
Article first time published onWhat is a 211 spray tip used for?
The 211 spray tip is used to work with light lacquers and spray more accurately. For example, to paint beams and window frames. To paint larger surfaces, such as ceilings or tables, it would be more appropriate to use a 411 spray tip with lacquers or paints / interior materials.
What is a 411 spray tip used for?
The reversible RAC IV SwitchTips are the most widely used tip for spraying a variety of coatings from lacquers to exterior paints. Use the Reverse-A-Clean (RAC) feature to quickly clear tip clogs by simply twisting the tip and spraying in the reverse position.
What is a 213 spray tip used for?
The 213 SwitchTip has a 0.013 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs. Used for residential, commerical or industrial applicaitions. Best used with materials ranging from lacquers, latex paints and mastics.
What is a 517 spray tip used for?
The reversible RAC IV SwitchTips are the most widely used tip for spraying a variety of coatings from lacquers to exterior paints. Use the Reverse-A-Clean (RAC) feature to quickly clear tip clogs by simply twisting the tip and spraying in the reverse position.
What is a 525 spray tip used for?
The Reverse-A-Clean (RAC) 525 RAC 5 SwitchTip produces a 10 to 12 inch fan and has a 0.025 inch orifice. Reverse the SwitchTip to easily clear clogs. Used for residential, commerical or industrial applicaitions. Best used with materials ranging from lacquers, latex paints and mastics.
What is a 417 spray tip used for?
Achieve greater control and less overspray on different surfaces with a wide range of coatings, from stains to exterior paints. 8 inch spray pattern ideal for larger surfaces such as interior or exterior walls.
Do you spray ceilings or walls first?
Spray the walls before the ceiling. Allow the wall paint to fully dry, cover the walls with tape and plastic, and spray the ceiling. Masking walls is a lot easier than masking a ceiling upside down if you were to spray the ceiling before the walls.
Are Graco and Wagner tips interchangeable?
These are usually ⅞ fitting, and they’re interchangeable between the different brand guns. Graco FFLP fit in the Graco RAC-X holder, while Wagner HEA use the Trade Tip 3 holder (e.g. an FFLP tip will not fit on a Wagner gun without swapping over the tip holder, etc.)
Why does my airless paint sprayer leaving streaks?
Answer: Streaks in the spray pattern, especially heavy bands at the outside edge, indicates low pressure at the tip. … Using a tip that is larger than the maximum size or a tip that is worn larger will cause low pressure. The tip should also be the proper size for the type of material being sprayed.
What is a 415 spray tip used for?
Achieve greater control and less overspray on different surfaces with a wide range of coatings, from stains to exterior paints. 8 inch spray pattern ideal for larger surfaces such as interior or exterior walls.
Is spray painting walls easy?
Using a powered paint sprayer is a quick and efficient way to paint a room. The preparation time might feel longer, but the short time it takes to apply the paint quickly makes up for this.
What is a 513 spray tip used for?
The Reverse-A-Clean (RAC) 513 RAC IV SwitchTip is designed for narrow surfaces and thinner materials like stains and polyurethanes. The 513 SwitchTip has a 0.013 inch orifice and produces a 10 to 12 inch fan. Reverse the SwitchTip to easily clear clogs.
What does tip size mean?
Tip Size. The size of this opening controls how much coating material can flow out through the tip. The larger the orifice, the more paint can come through it. The amount of pressure used will also influence this.
Can you use latex paint in HVLP spray?
HVLP systems are not designed to spray heavier bodied latex paint. … The pressurized cup allows the paint to be pushed to the fluid nozzle because of the added pressure behind the paint. If you look at most professional airless paint sprayers designed for latex paint, they are actually pumps, and use no air.
What is a 619 spray tip used for?
The 619 HEA tip will spray latex paint and heavy primers with 55% less overspray. The 12-14 in. spray pattern and soft feathered edges make this an ideal tip for high production exterior painting and priming applications.
What tips fit Krause and Becker?
The Krause and Becker Airless Paint Sprayer comes with a 517 tip, but we discovered that this airless paint sprayer does a great job with a fine finish tip as well.
What is a 313 tip used for?
Product Description. The reversible RAC IV SwitchTips are the most widely used tip for spraying a variety of coatings from lacquers to exterior paints. Use the Reverse-A-Clean (RAC) feature to quickly clear tip clogs by simply twisting the tip and spraying in the reverse position.
Can you use textured paint in a sprayer?
One of the greatest things about an Airless Texture Sprayer is the capability to not only to spray texture materials, but to also spray paint. … Spray texture or paint. It’s just that simple.
Will Graco tips fit Avanti sprayer?
This AVANTI® 519 Paint Spray Tip is easy to use, easy to clean. … Fits AVANTI® and BAUER™ airless paint sprayers and most major competitors including GRACO and TITAN.
What tips come with the Graco X5?
Answer: X5 comes with a 515, and has a Max Tip Size of . 015″ (i.e. 215, 315, 415, 615). It is not recommended you use a tip size higher than .
What size is a Graco 515 tip?
Graco TrueAirless 515 0.015-in Hole 0.65-in Length Paint Sprayer Tip.
